| Tip disc frâna | plin |
| Numar gauri | 4 |
| Diametru exterior [mm] | 290 |
| Diametru de centrare [mm] | 71 |
| Înaltime [mm] | 34,9 |
| Grosime disc frâna [mm] | 12 |
| Grosime minima [mm] | 10 |
| Asezare gauri ø [mm] | 108 |
| Alezaj-? 1 [mm] | 13 |
| Alezaj ø 2 [mm] | 8,7 |
| Culoare | negru |
| Suprafata | lacuit |
| Aprobare | E1 90R-02 C0190/0523 |
| CITROËN | C4 II (NC) | 1.6 THP 155 | 11-2009 / 12-2016 | hatchback | KW: 115 | CP: 156 | CMC: 1598 | motor pe benzina |
| CITROËN | DS4 (NX) | 1.6 THP 200 | 04-2011 / 07-2015 | hatchback | KW: 147 | CP: 200 | CMC: 1598 | motor pe benzina |
| CITROËN | DS4 (NX) | 2.0 HDi 165 | 04-2011 / 07-2015 | hatchback | KW: 120 | CP: 163 | CMC: 1997 | motor diesel |
| PEUGEOT | 308 CC (4B) | 1.6 THP | 10-2010 / 12-2014 | Cabriolet | KW: 147 | CP: 200 | CMC: 1598 | motor pe benzina |
| CITROËN | DS5 | 1.6 THP 200 | 11-2011 / 07-2015 | hatchback | KW: 147 | CP: 200 | CMC: 1598 | motor pe benzina |
| PEUGEOT | 308 I (4A, 4C) | 1.6 GTi | 07-2010 / 10-2014 | hatchback | KW: 147 | CP: 200 | CMC: 1598 | motor pe benzina |
| CITROËN | DS4 (NX) | 1.6 THP 165 | 01-2012 / 07-2015 | hatchback | KW: 121 | CP: 165 | CMC: 1598 | motor pe benzina |
| CITROËN | DS5 | 2.0 BlueHDi 180 | 08-2013 / 07-2015 | hatchback | KW: 133 | CP: 180 | CMC: 1997 | motor diesel |
| PEUGEOT | 3008 microbus (0U) | 2.0 HDi Hybrid4 (0URHCA) | 02-2011 / 08-2016 | microbus | KW: 147 | CP: 200 | CMC: 1997 | Complet hibrid |
| CITROËN | DS5 | 2.0 HDi 200 Hybrid4 tractiune integrala | 12-2011 / 07-2015 | hatchback | KW: 147 | CP: 200 | CMC: 1997 | Complet hibrid |
| CITROËN | DS4 (NX) | 2.0 HDi / BlueHDi 135 | 09-2011 / 07-2015 | hatchback | KW: 100 | CP: 136 | CMC: 1997 | motor diesel |
| CITROËN | DS4 (NX) | 1.6 THP 150 | 04-2011 / 07-2015 | hatchback | KW: 110 | CP: 150 | CMC: 1598 | motor pe benzina |
| CITROËN | DS5 | 1.6 THP 165 Hybrid | 06-2012 / 07-2015 | hatchback | KW: 121 | CP: 165 | CMC: 1598 | Complet hibrid |
| CITROËN | C4 II (NC) | 1.2 THP 130 | 04-2014 / prezent | hatchback | KW: 96 | CP: 130 | CMC: 1199 | motor pe benzina |
| CITROËN | DS4 (NX) | 1.6 BlueHDi 120 | 07-2014 / 07-2015 | hatchback | KW: 88 | CP: 120 | CMC: 1560 | motor diesel |
| CITROËN | DS4 (NX) | 2.0 BlueHDi 180 | 07-2014 / 07-2015 | hatchback | KW: 133 | CP: 180 | CMC: 1997 | motor diesel |
| CITROËN | DS4 (NX) | 2.0 BlueHDi 150 | 07-2014 / 07-2015 | hatchback | KW: 110 | CP: 150 | CMC: 1997 | motor diesel |
| CITROËN | DS4 (NX) | 1.2 THP 130 | 07-2014 / 07-2015 | hatchback | KW: 96 | CP: 130 | CMC: 1199 | motor pe benzina |
| DS | DS 4 / DS 4 CROSSBACK (NX) | 1.2 THP 130 (NXHNYM) | 07-2015 / 12-2018 | hatchback | KW: 96 | CP: 130 | CMC: 1199 | motor pe benzina |
| DS | DS 4 / DS 4 CROSSBACK (NX) | 1.6 THP 165 | 07-2015 / 12-2018 | hatchback | KW: 121 | CP: 165 | CMC: 1598 | motor pe benzina |
| CITROËN | 4249 F7 |
| DS | 4249 F7 |
| PEUGEOT | 4249 F7 |
Disc frana 11-15 523 0012/PD MEYLE
Producător: MEYLE
Cod produs: 11-15 523 0012/PD
131,07 RON
Disc frana QD0690 QUARO
Producător: QUARO
Cod produs: QD0690
155,82 RON
Disc frana 0 986 479 118 BOSCH
Producător: BOSCH
Cod produs: 0 986 479 118
150,12 RON
Disc frana DF6632 TRW
Producător: TRW
Cod produs: DF6632
168,27 RON
